Diesel Forklift

CPCD80H

  • Features
  • Parameter





8T Internal Combustion Counterbalance Forklift Truck
CPCD80H
Features Powe type 柴油Diesel
Rated load kg 8000
Load center distance mm 600
Lift height mm 3000
Free lift height mm 185
Fork size  L×W×T mm 1220×150×80
 Mast tilt angle FR/RR 。 6/12
Minimum turning radius mm 3370
 Minimum right angle stacking aisle width mm 5310
Minimum right angle aisle width mm 3100
Minimum ground clearance Frame center(no load) mm 220
Mast Bottom（no load） mm 205
Height of overhead guard mm 2500
Performance Maximum travel speed Full load km/h 24
No load km/h 25
Maximum lift speed Full load mm/s 400
No load mm/s 430
Maximum drawbar pull Full load KN 53
Maximum gradeability % 20
Dimensions Overall length Without forks mm 3610
Overall width mm 2075
Mast lowered height mm 2510
